Laowa Aurogon FF 10-50x NA0.5 supermicro APO Sony FE
- Medium Format | NA0.5 to NA0.15
- 10-50x Supermicro APO Lens System
- Objective Lens, Four Magnification Tubes
- Fixed 0.79" Focus Distance
- Unclicked Manual Aperture Ring
- Apochromatic Elements
- Aluminum Carrying Case
Laowa Aurogon FF 10-50x NA0.5 supermicro APO Sony FE
Special Financing | Shoot Now - Pay Later!
Get the gear you want today and pay tomorrow with one of our special financing programs.
Laowa Aurogon FF 10-50x NA0.5 supermicro APO Sony FE
The Laowa Aurogon FF 10-50x NA0.5 Supermicro APO for Sony E from Venus Optics is a microphotography lens system that can be directly used on cameras without the need to use microscope adapters. It features four seamlessly interchangeable magnification tubes, offering 10x, 20x, 35x, and 50x magnification options. The adjustable numerical aperture (NA) of this microscope lens ranges from 0.5 to 0.1, the high NA providing room for exceptional brightness and minimal diffraction. The lens is designed with a fixed 0.79" long working distance, ensuring both flexibility and convenience for the lighting setup, and you can easily change magnification without having to reset focus and lighting for stable microscopic shooting setups.
The apochromatic lens design minimizes chromatic aberrations in all magnification ratio for outstanding resolution. The eight grades of Numerical Aperture (NA) values from 0.5 to 0.15 indicated on the objective lens addresses the depth of field for microscopic shooting. The wide NA provided combined with ample lighting ensures that when capturing images, a lower ISO value can be used, resulting in a higher resolution image. The Laowa Aurogon is suitable for use in both still and video applications.
Objective Lens plus Magnification Tube Equivalent Focal Length
- 10x: 18.8mm
- 20x: 10.3mm
- 35x: 6.85mm
- 50x: 5.56mm
Maximum Distortion
- 10x: 0.60%
- 20x: 0.80%
- 35x: 0.40%
- 50x: 0.40%
Image Field Diameter
- 10x: Column 2 Value 15
- 20x: Column 3 Value 15
- 35x: Column 4 Value 15
- 50x: Column 5 Value 15
Conjugate Distance
- 10x: 11.8"
- 20x: 14.6"
- 35x: 16.5"
- 50x: 18.3"
Component Lengths
- Objective Lens Only: 6.6"
- 10x Magnification Tube: 4.4"
- 20x Magnification Tube: 6.4"
- 35x Magnification Tube: 8.3"
- 50x Magnification Tube: 9.9"
Component Weights
- Objective Lens Only: 13.8 oz
- 10x tube: 13.3 oz
- 20x tube: 15.7 oz
- 35x tube: 1.17 lb
- 50x tube: 1.34 lb
- Objective Lens
- 10x Magnification Tube
- 20x Magnification Tube
- 35x Magnification Tube
- 50x Magnification Tube
- Aluminum Carrying Case
- Limited 3-Year Manufacturer Warranty
| Magnification | 10x, 20x, 35x, 50x |
| Adjustable numerical aperture | 0.5/0.45/0.4/0.35/0.30/0.25/0.2/0.15 |
| Lens Format | Full Frame |
| Working distance | 0.78" (20mm) |
| Aperture blades | 9 |
| Wavelength range | 435-656nm |
| Objective lens + tube lens focal length | 18.8mm 10.3mm, 6.85mm, 5.56mm |
| Special tube lens for Laowa model | Magnification tube: 10x, 20x, 35x, 50x |
| Maximum distortion | 10x: 0.60% 20x: 0.80% 35x: 0.40% 50x: 0.40% |
| Image field diameter | Full frame: 0.94 x 1.41" (24 x 36mm) |
| Conjugate distance | 10x: 11.78" (299.4mm) 20x: 14.56" (370mm) 35x: 16.54" (420.2mm) 50x: 18.31" (465.1mm) |
| Dimensions (L x Dia.) | Objective Lens: 6.57 x 1.96" (167 x 50mm) 10x Magnification Tube: 4.41 x 2.75" (112 x 70mm) 20x Magnification Tube: 6.41 x 2.75" (163 x 70mm) 35x Magnification Tube: 8.26 x 2.75" (210 x 70mm) 40x Magnification Tube: 9.96 x 2.75" (253 x 70mm) |
| Weight | Objective Lens: 13.75 oz (390g) 10x Magnification Tube: 14.84" (377g) 20x Magnification Tube: 17.48" (444g) 35x Magnification Tube: 20.86" (530g) 40x Magnification Tube: 23.97" (609g) |
- Objective Lens
- 10x Magnification Tube
- 20x Magnification Tube
- 35x Magnification Tube
- 50x Magnification Tube
- Aluminum Carrying Case
- Limited 3-Year Manufacturer Warranty
