RODE RODECaster Video All-in-One Production Console
Product Features
- Switcher with Integrated Audio Mixer
- 4 x HDMI & 2 x USB-C Inputs
- Supports up to 1080p60
- RTMP Streaming via Ethernet or Wi-Fi
- 20 x Audio Sources, 9 x Stereo Channels
- 9 x Mix/Effect Layers
- Digital USB Audio Ports
- 2 x Combo XLR-1/4", High-Gain Preamps
- Aphex VoxLab Audio Processing
- Bluetooth 5.3 and Wi-Fi 6 Connectivity
RODE RODECaster Video All-in-One Production Console
Model # RCV
Out of Stock
RODE RODECaster Video All-in-One Production Console
The RØDECaster Video is a revolutionary all-in-one video and audio production console that provides intuitive control over every element of your content. Combining powerful video switching, recording and production capabilities with a fully integrated professional audio mixer, it offers a seamless way to streamline and supercharge your workflow for studio productions, video podcasts and interviews, and stream live events with broadcast quality.
What's in the box
- RODE RODECaster Video All-in-One Production Console
- 2 x External Antenna
- SuperSpeed USB-C to USB-C Cable
- Power Supply
- Limited 1-Year Manufacturer Warranty Registration Extension: 1-Year
698813014507
Specifications
| Available M/E Layers | 9 M/E |
| Effect Types | 2x Chroma Key |
| Downstream Keys | 2x Overlay |
| Audio Mixing | 20-Channel Mixing |
Processing
| Switching Type | Pushbutton |
| Processing Resolution | 1080p at 23.98/24/25/29.97/30/50/59.94/60 |
| Color Processing | 8-Bit 4:4:4 RGB |
Input
| Number of Video Input Sources | 6 |
| Video Inputs | 4x HDMI (1.4b) 2x USB-C (UVC) |
| Input Video Format | HDMI (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 25/29.97/30 fps USB-C (4:4:4/4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps |
| Audio Inputs | 2x Combo XLR-1/4" TRS 5x Proprietary (Shared with Video) |
| Embedded Audio Input | Wireless USB-C HDMI |
Output
| Video Output Channels | 2 |
| Video Outputs | 2x HDMI |
| Output Video Format | HDMI (8-Bit 4:4:4 RGB, YUV) 1080p at 24/25/30/50/60 fps |
| Audio Outputs | 2x 1/4" TRS 2x 1/4" TRS Line |
Connectivity
| Inputs/Outputs | 3x USB-C(Stereo) |
| Other I/O | 1x RJ45 LAN |
| HDCP Support | No |
| IP Video | 1920 x 1080 at 23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p Encoding |
| Transport Protocols | RTMP |
| Compatible Services | Facebook Live, Twitch, YouTube Live |
| Recording Media | 1x microSD (Unspecified Type) |
| Recording Modes | 1920 x 1080p (H.264/AVC) |
Display
| Display Size | 2" |
Hardware
| OS Compatibility | macOS 10.15 or Later / Windows 10 to 11 |
| OS Compatibility | macOS 10.15 or Later Windows 10.1803 or Later Windows 11 |
| Processor | Not Specified by Manufacturer |
| Wi-Fi | Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) |
| Bluetooth | 5.3 |
| Power I/O | 1x USB-C Input |
| Power Consumption | Power Supply: 20 VDC at 3 A (60 W) |
General
| Dimensions | 12 x 5.2 x 2.4" / 305.9 x 132 x 61.4 mm |
| Weight | 2.8 lb / 1257 g |
What's Included
- RODE RODECaster Video All-in-One Production Console
- 2 x External Antenna
- SuperSpeed USB-C to USB-C Cable
- Power Supply
- Limited 1-Year Manufacturer Warranty Registration Extension: 1-Year
